B&C 8CX21 - 8 ohm 8" 25W/200W Pro Audio Coaxial Driver
B&C 8CX21 - 8 ohm 8" 25W/200W Pro Audio Coaxial Driver
  • B&C 8CX21 - 8 ohm 8" 25W/200W Pro Audio Coaxial Driver
  • B&C 8CX21 - 8 ohm 8" 25W/200W Pro Audio Coaxial Driver
Product Details ＋

8" high efficiency co-axial driver.

SPECIFICATIONS

Nominal Diameter:
Nominal Impedance:
Nominal Power LF Unit:
Nominal Power HF Unit:
Freq. Response:
Sensitivity LF:
Sensitivity HF:
Voice Coil Diameter LF Unit:
Voice Coil Diameter HF Unit:


8.0", 203mm
8 ohms
200 W rms, 400 W program
25 W rms, 50 W program
75 Hz-20.0 kHz
94 db 1w/1m
101 db 1w/1m
2.0", 52mm
1.4", 36mm
MOUNTING INFORMATION

Overall Diameter:
Baffle Hole Dia:
Mounting BCD:
Depth:


8.8", 225mm
7.36", 187mm
8.3", 210mm
5.3", 135mm
T/S PARAMETERS

Fs:
Re:
Le:
Qms:
Qes:
Qts:
Vas:
Xmax:


74.0 Hz
5.2 ohms
1.2mH
4.1
0.39
0.36
15 L, 0.55 cuft
5mm
CONSTRUCTION

-Cast basket
-Ceramic magnet
B&C 8CX21 - 8 ohm 8" 25W/200W Pro Audio Coaxial Driver
  • DefaultTitle

$ 88.47

$ 68.05
